Lead-Acid Batteries

Energo lead-acid batteries offer VRLA and flooded solutions for reliable energy storage in UPS, DC power and standby systems. Selection considers capacity, autonomy, discharge characteristics, ambient temperature and expected service life.

Request a quote →
Kurşun Asit Aküler için ürün ve uygulama imagei
ENERGO GENERAL SERIES

Energo Lead-Acid Battery Models

Energo GP 1.3 product image

Energo GP 1.3

A 12 V 1.3 Ah VRLA AGM battery providing backup power for UPS, alarms, telecom and emergency lighting.

12V 1.3AhProduct details →Energo GP 7 product image

Energo GP 7

Energo GP7 is a maintenance-free VRLA AGM lead-acid battery with a nominal voltage of 12V and capacity of 7Ah.

12V 7AhProduct details →Energo GP 9 product image

Energo GP 9

Energo GP9 is a 12V 9Ah VRLA AGM battery designed for stationary and backup-power applications.

12V 9AhProduct details →Energo GP 12 product image

Energo GP 12

Energo GP12 is a maintenance-free 12V 12Ah VRLA AGM lead-acid battery. Applications include UPS, security, telecommunications, emergency lighting, control panels and DC standby systems.

12V 12AhProduct details →Energo GP 18 product image

Energo GP 18

Energo GP18 is a maintenance-free 12V 18Ah VRLA AGM lead-acid battery.

12V 18AhProduct details →Energo GP 24 product image

Energo GP 24

Energo GP24 is a maintenance-free 12V 24Ah VRLA AGM lead-acid battery.

12V 24AhProduct details →Energo GP 33 product image

Energo GP 33

Energo GP33 is a maintenance-free 12V 33Ah VRLA AGM lead-acid battery for applications including UPS.

12V 33AhProduct details →Energo GP 40 product image

Energo GP 40

Energo GP40 is a maintenance-free 12V 40Ah VRLA AGM lead-acid battery.

12V 40AhProduct details →Energo GP 60 product image

Energo GP 60

Energo GP60 is a maintenance-free 12V 60Ah VRLA AGM lead-acid battery.

12V 60AhProduct details →Energo GP 80 product image

Energo GP 80

Energo GP80 is a maintenance-free 12V 80Ah VRLA AGM lead-acid battery.

12V 80AhProduct details →Energo GP 100 product image

Energo GP 100

Energo GP100 is a maintenance-free 12V 100Ah VRLA AGM lead-acid battery.

12V 100AhProduct details →Energo FT 150 product image

Energo FT 150

Energo FT150 is a maintenance-free 12V 150Ah front-terminal VRLA AGM battery.

12V 150AhProduct details →

PRODUCT AND TECHNOLOGY

Role in the system and operating principle

01

Product description

Lead-acid batteries are an established, reliable energy-storage technology for UPS, industrial DC, telecom, security and emergency applications. VRLA AGM, gel and flooded options suit different autonomy, discharge and maintenance requirements.

02

Operating principle

Positive lead-dioxide and negative lead electrodes react electrochemically in sulphuric-acid electrolyte to produce electrical energy. Charging reverses the reaction to restore stored energy. Usable capacity depends on temperature, discharge current, end voltage and ageing.

03

Maintenance and lifecycle

Battery life is directly related to temperature, charging voltage, depth of discharge and cycle count. Periodic voltage, temperature, connection and capacity checks help identify performance loss early. Flooded batteries also require electrolyte-level and density checks.

APPLICATIONS

Engineering for the duty profile.

TYPICAL OPTIONS

Technical framework confirmed in the quotation

Values and options are for initial selection. Final values are determined after the selected product, manufacturer data, specification and site conditions have been verified.

ParameterTypical optionSelection basis
TechnologyVRLA AGM / gel / floodedAccording to the application
Block or cellVoltage and service approachAccording to system design
CapacityAh / W-cellAccording to autonomy calculations
TemperatureReference and site valuesAccording to life calculations
Rack / cabinetOpen, enclosed, seismicAccording to site requirements

SYSTEM ARCHITECTURE

Topology, protection and control

Topology and redundancy

  • Block- or cell-based string
  • Single or parallel strings
  • Rack or cabinet installation
  • Central or string-level protection

Protection features

  • Battery fuse/DC breaker
  • Short-circuit and contact safety
  • Temperature and ventilation control
  • Current sharing in parallel strings

Control and communication

  • UPS/rectifier charging algorithm
  • String and block-voltage monitoring
  • Temperature compensation
  • Conductance or capacity monitoring option

Options

  • AGM, gel or flooded type
  • Battery cabinet and rack
  • Block monitoring
  • External battery breaker
  • Temperature sensor

COMPARISON

Compare battery technologies by application

TechnologyPrincipal application strengthCritical selection checks
Ni-CdDemanding temperatures, long service and high reliabilityDuty profile, end voltage and manufacturer discharge tables
Lead-acidEstablished UPS/DC infrastructure and a range of cost optionsTemperature, autonomy, discharge power and expected life
Li-ionHigh energy density, cycling and advanced BMSChemistry, BMS/UPS compatibility, thermal and fire-safety approach
Na-ionEmerging stationary storage and pilot applicationsActual product data, references, maturity and supply assurance

PROJECT INPUTS

Information for the right selection

Unknown values can be clarified through site inspection and engineering before quotation.

  1. 01

    Constant-power/current load and autonomy

  2. 02

    End voltage and DC bus limits

  3. 03

    Ambient and design temperature

  4. 04

    Expected service life and cycling

  5. 05

    Space, weight, rack and cable conditions

TECHNICAL QUESTIONS

Frequently asked questions

Are VRLA batteries maintenance-free?

No water topping-up does not mean no inspection. Connections, voltage, temperature and capacity must be monitored.

Why is battery life shortened?

High temperature, insufficient charging, frequent deep discharge and cell imbalance are principal factors.
